Factory Cat GTX Heavy Duty
Scrubbers
Disk and Cylindrical / 25'' - 34''
Down Pressure
Up to 200 lbs / with Auto Adjust
Power
Battery / Up to 5.0 hours Runtime
Tank Capacity
33 Gallons
For questions, call 01282 416139
Machine Summary
Factory Cat’s GTX Rider Floor Scrubber Dryer is known for its simple design and durable construction, offering unmatched value for the customer. The GTX Floor Scrubber Dryer comes equipped with a powerful front-wheel drive for climbing ramps and max operator ease.
While keeping with the constant durability that Factory Cat machines have to offer, your operators will find the GTX Floor Scrubber Dryer easy to manoeuvre and simple to service. The deck is protected by heavy duty metal shrouds or large polyurethane rollers to keep the unit from marking walls and your investment safe.
For questions call 01282 416139
Your data is protected view our Privacy Policy
Media click the images to enlarge
Technical Details
Body Construction / Dimensions
Tank Material | Poly 3/8'' (9.5 mm) |
Chassis Construction | 3/16'' (4.8 mm) & 1/8'' (3.1 mm) Steel Powder Coated Steel |
Front Wheel (Diameter × Width) | 10'' × 3'' (25.4 × 7.6 cm) - Solid Grey, Non-Marking |
Rear Wheels (Diameter × Width) | (2×) 12'' × 3'' ([2×] 30.5 × 7.6 cm) - Solid Grey, Non-Marking |
Size (L × W × H) | 64'' × 34'' × 56'' (162.6 × 86.4 × 142.2 cm) |
ST/HD Weight (w/o Batteries) | 725 lbs (328.85 kg) - 850 lbs (350.55 kg) |
ST/HD Weight (w/ Batteries) | 1,195 lbs (542 kg) - 1,325 lbs (601 kg) |
Brush / Pad System
Disk Dimensions | 26'' - (2×) 13'' Ø (66.0 - [2×] 33.0 cm) |
28'' - (2×) 14'' Ø (71.1 - [2×] 35.6 cm) | |
30'' - (2×) 15'' Ø (76.2 - [2×] 38.1 cm) | |
34'' - (2×) 17'' Ø (86.4 - [2×] 43.2 cm) | |
Cylindrical Dimensions | 25'' - (2×) 6'' Ø x 23'' (63.5 - [2x] 15.2 x 58.4 cm) |
29'' - (2×) 6'' Ø x 27'' (73.7 - [2x] 15.2 x 68.6 cm) | |
33'' - (2×) 6'' Ø x 31'' (83.8 - [2x] 15.2 x 78.7 cm) | |
Cylindrical Brush Speed | HD: 825 rpm / ST: 650 rpm |
ST Motors (Disk & Cylindrical) | (2×) 0.75 hp / 350 rpm ([2×] 550 watts) |
HD Motors (Disk & Cylindrical) | (2×) 1.5 hp / 350 rpm ([2×] 1,118.6 watts) |
Brush Pressure Settings | (5) with Auto Adjust |
Brush Down Pressure | Up to 200 lbs (91 kg) / 500 lbs (226.8 kg) Actuator Rating |
Power System
System Voltage | 36 VDC |
ST Standard Battery | 210 ah WET |
ST Optional Batteries | 240 ah WET & 250 ah AGM |
HD Standard Battery | 310 ah WET |
HD Optional Batteries | 360 ah WET / 335 ah AGM |
Run Time* | Up to 5.0 Hours* |
ST Charger | 120VAC / 60 Hz Input - 36VDC / 25 amp Output |
HD Charger | 120VAC / 60 Hz Input - 36VDC / 30 amp Output |
Drive System
Power | 1.0hp - All Gear / Sealed (745 watts) |
Forward Speed | 0 - 320 ft/min / 0 - 3.6 mph (0 - 98 m/min / 0 - 6 km/h) |
Scrubbing Speed | 0 - 256 ft/min / 0 - 2.9 mph (0 - 78 m/min / 0 - 5 km/h) |
Reverse Speed | 0 - 230 ft/min / 0 - 2.6 mph (0 - 70 m/min / 0 - 4 km/h) |
Solution / Recovery Systems
Solution Tank Capacity | 33 Gallons (124.9 liters) - w/ Graduated Site Tube |
Solution Flow / Filter | 0 - 0.7 GPM / Stainless Inline (0 - 2.6 LPM) |
Recovery Tank Capacity | 6 Gallons (136.3 liters) - 1.5'' diameter Drain Hose |
Demisting Chamber | 1.25 Gallons (4.7 liters) |
Drain Saver | 130 cubic inches (2,130.3 cm3 ) |
Vacuum Power | 1.0 hp / 2 Stage / 6.6'' (710 watts / 16.5 cm) |
Vacuum Specs (Water Lift / Airflow) | 73'' / 96 cfm (185.4 cm / 2.7 cm/m) |
Squeegee | Curved w/ 4-sided Rear Blade & Quick Change Latch |
26D, 25C, - 30'' (76.2 cm) | |
28D, 30D, 29C - 33'' (83.8 cm) | |
34D, 33C - 36'' (91.4 cm) |
General
Cleaning Width | 26'', 28'', 30'' & 34'' - Disk (66.0, 71.1, 76.2 & 86.4 cm) |
25'', 29'' & 33'' - Cylindrical (63.5, 73.7 & 83.8 cm) | |
Sound Levels | 70 dBA* |
Productivity - Theoretical | Up to 46,875 sqft (4,354.8 sqm)** |
Productivity - Practical | Up to 21,661 sqft (2,012.4 sqm)** |
*Decibel levels per ISO 11201 as recommended by the American Association of Cleaning Equipment Manufacturers & OSHA | |
**Productivity is based off of ISSA 2010 Cleaning Times |
